HDMI 1.3 and HDCP 1.4 compliant
-
Video resolution up to 1920×1200@60Hz 4:4:4
-
Support 4.95Gbps video bandwidth
-
Signal transmission distance can be extended up to 328ft / 100m via CAT5E/6/6A/7 cable
-
Support point-to-point signal extension
-
Support signal distribution, multicast mode, distributed matrix and video wall (up to 9×9) functions over a 1G Network Switch
-
Intelligent video wall management makes it achievable of novel layout of wall configurations
-
Support LPCM 2.0CH (32/44.1/48KHz) audio format
-
Support audio embedding and extracting
-
Support RS-232 control (pass-through & Guest mode)
-
Support main stream and sub stream encoding modes
-
Stream parameters can be configured via Web GUI or Controller Box
-
Controlled via RS-232, TCP/IP, Web GUI and Controller Box
-
Support POE function (802.3af Class 3, PD mode)
-
Smart networking design for easy and flexible installation
| Input and Output | |
| Inputs & Outputs | 1x HDMI 1.3 IN [Type A, 19-pin female] , 1x AUDIO IN/OUT [3-pin phoenix connector] |
| Inputs Resolution | Up to 1920×1200@60Hz 4:4:4 |
| Network | 1x LAN [RJ45 connector, POE] 1x RS-232 [3-pin phoenix connector |
| General Features | |
| Video Bandwith | 4.95Gbps |
| Color Space | RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 |
| Video Compression Standart | H.265/H.264 |
| Color | 8/10/12bit |
| HDCP | HDCP 1.4 |
| Audio Formats | LPCM 2.0CH (32/44.1/48KHz) |
| Transmission Distance | 100m (CAT5E/6/6A/7) |
| Management Features | |
| Management and Control | RS-232, TCP/IP, Web GUI, and Controller Box |
| Others | |
| Power Connection | AC100 – 240V 50/60Hz |
| Working Temperature | 14 – 113°F / -10 – 45°C |
| Humidity Range | 20 – 90% RH (no condensation) |
| Storage Temperature | -4 – 140°F / -20 – 60°C |
| Dimensions | 120mm × 95mm × 21.5mm – Width/Depth/Height, Metal Enclosure |
| Weight | 2.94kg |
| Power Value/Consumption | 2.64W Max |
| Mounting | 1U Rack Mount |
| ESD Protection | ±8kV (Air-Gap Discharge) & ±4kV (Contact Discharge) |
| Certifications | |
| EU/USA | CE/FCC/UL |
| Package Details | |
| Package Contents | 1 x 1080P over IP 100M/1GbE Encoder 2 x 3-pin Phoenix Connector (3.81mm, male) 4 x Machine Screw (KM3, 4mm) 2 x Mounting Ear 1 x 12V/1A Locking Power Adapter 1 x User Manual |
