4 X USB Type-B Input
-
4 X USB Type-A Output
-
Support Mouse Slide Screen Function. In different modes, one set of keyboard and mouse can move left and right or up and down on four computer monitors, and the user can select one host to operate.
-
Built-in Web GUI can set Synchronous Control Function (One set of mouse and keyboard can control all connected computers simultaneously).
-
Support three mode switch methods: mode switch button, keyboard hotkeys and Web GUI (User can define the placement mode in the User Defined Mode).
-
Support USB power supply
-
Simple to install, plug and play
Input and Output | |
Inputs | 4 x USB1.1 Type-B Host |
Outputs | 4 x USB 1.1 Type-A |
General Features | |
Datta TRansfer Rate | Up to 12Mbps (1.5MB/S) |
Management Features | |
Management and Control | Front Panel Control, TCP/IP Web GUI, RS232 (3pin Phoenix) with API |
Others | |
Power Connection | DC 5V/1A, Support USB power supply |
Working Temperature | 32 – 104°F / 0 – 40°C |
Humidity Range | 20 – 90% RH (no condensation) |
Storage Temperature | -4 – 140°F / -20 – 60°C |
Dimensions | 142mm × 82mm × 21mm – Width/Depth/Height, Metal Enclosure |
Weight | 315g |
Power Value/Consumption | 1.45W |
Mounting | Desktop / Rack Mount |
ESD Protection | ±8kV (Air-Gap Discharge) & ±4kV (Contact Discharge) |
Certifications | |
EU/USA | CE/FCC/UL |
Package Details | |
Package Contents | 1 × USB 4-Port Roaming Mouse Switcher 1 × 5V/1A Power Supply (US standard) 4 × USB Cable (1.5 meters) 1 × User Manual |
