- Real-time H.265/HEVC and H.264 Ultra HD video encoding
- HDMI 2.0b compatible
- Supports input resolutions up to 3840×2160@60Hz with 4:4:4 color sampling
- Supports video bandwidth up to 18Gbps
- Simultaneous triple-stream output:
- Main stream: H.265 or H.264 up to 4K@60Hz
- Secondary stream: H.264 up to 1080p@30Hz
- Preview stream: JPEG up to 1280×720@5fps
- Supports RTSP over UDP or TCP
- Supports RTP/UDP, TS/UDP, RTMP and RTMPS streaming
- Supports unicast and multicast transmission
- Configurable bitrate, resolution, frame rate and EDID
- Stream controls including play, pause and stop
- Audio-only streaming and configurable audio delay
- Supports LPCM 2.0CH audio at 48kHz
- HDMI loop-out for local 4K monitoring
- Analog audio embedding and de-embedding
- Image preview through the management interface
- Supports point-to-point extension and one-to-many signal distribution
- Third-party API integration through Telnet, SSH or TCP socket connections
- HTTP and HTTPS Web GUI management
- Device discovery with “Show Me” identification
- IEEE 802.1X network authentication
- 100Mbps/Gigabit Ethernet connectivity
- IEEE 802.3af PoE powered-device support
- Front-panel OLED status display
- Compatible with 4TheWall 1U and 6U V2 rack-mount systems
| Input and Output | |
| Inputs & Outputs | 1 x HDMI2.0b input, 1 x HDMI2.0b loopback output Max support 4K@60Hz, 1 x Stereo audio In (3.5 mm) input and output |
| Inputs Resolution | Up to 4K@60Hz 4:4:4 |
| Outputs Resolution | Push stream resolution: Same as input, 3840×2160, 1920×1080, 1280×720, 640×480 Push stream frame rate: 5~60Hz |
| Network | 1x LAN (POE) (RJ45 connector), Gigabit |
| General Features | |
| Video Bandwith | 18Gbps |
| Color Space | RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 Push stream encoding: 4:2:0 |
| Video Compression Standart | H.265/H.264 – 0.1 to 32 Mbps bitrate and 5 to 60 Fps support – VBR or CBR HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) ONVIF |
| Color | 8/10/12bit (HDMI Input) 8 bit Push Stream Output |
| Audio Formats | LPCM 2CH 48KHz |
| L/R Out Audio Parameters | Output Impedance: 330 Ohms Line Input / Output Level (Maximum): 2Vrms Frequency Response: (+0.5dB, -1dB) 20Hz to 20kHz Audio S/N Ratio: >90dB@2Vrms, 1kHzA-weighted Audio THD+N: <0.05%@2Vrms, 1KHz |
| Transmission Distance | 100m (CAT5E/6/6A/7) |
| Management Features | |
| Management and Control | TCP/IP, Web GUI, RS232 with API |
| Others | |
| Power Connection | AC100 – 240V 50/60Hz, DC 12V/1A |
| Working Temperature | 32 – 104°F / 0 – 40°C |
| Humidity Range | 20 – 90% RH (no condensation) |
| Storage Temperature | -4 – 140°F / -20 – 60°C |
| Dimensions | 130mm × 160mm × 30mm – Width/Depth/Height, Metal Enclosure |
| Weight | 659 gr |
| Power Value/Consumption | 7.2W (Max.) |
| Mounting | Desktop Aluminum+Iron – Black, Optional Rack Kit |
| ESD Protection | IEC 61000-4-2: ± 15kV (Air-gap discharge) & ± 8kV (Contact discharge) |
| Certifications | |
| EU/USA | CE/FCC/UL |
| Package Details | |
| Package Contents | 1 x 1080P60 AV Encoder 3 x 3pin-3.81mm Phoenix Connector (male) 1 x 12V/1A Locking Power Adapter 2 x Mounting Ear 4 x Machine Screw (KM3*4) 1 x User Manual |
