- HDCP 2.3 compliant
- Supports HDMI 2.0 resolutions up to 4K@60Hz with 4:4:4 8-bit color
- Supports 2K resolutions at 60Hz and 144Hz
- Supports ultra-wide display resolutions
- Supports HDR, HDR10, HDR10+, Dolby Vision and HLG pass-through
- Shares two monitors, one keyboard, one mouse and USB peripherals between two computers
- Supports dual-channel and hotkey switching
- Fast video switching
- Seamless keyboard and mouse switching
- EDID emulator on each input for stable display detection
- Virtual interaction function for waking compatible computers from standby
- USB 3.0 data transfer rates up to 5Gbps
- Shares printers, scanners, webcams, storage devices and other USB peripherals
- Hot-plug support for connected computers and USB devices
- Automatic switching
- Controlled via front-panel buttons, keyboard or mouse hotkeys, IR remote and RS-232
- Compatible with Windows, macOS and Linux
- Driver-free plug-and-play operation
- Zero-latency KVM interaction
- Compact design for easy and flexible installation
| Input and Output | |
| Inputs | 2 + 2 (4) HDMI 2.0 Type A (19-pin female) with 2 x USB 3.0 Type-B Host 1 x IR Input Fixed frequency 38KHz, 5Vp-p |
| Outputs | 2 x OUT (HDMI2.0 Type A, 19-pin female) 4 x USB DEVICE (USB-A, 9-pin female) 1 x L/R AUDIO OUT (3.5mm stereo) LPCM 2CH (sample rate 32~192kHz) |
| Inputs Resolution | Up to 4K@60Hz, 2K@60Hz/144Hz |
| Outputs Resolution | Up to 4K@60Hz, 2K@60Hz/144Hz |
| Control Ports | 1 x RS-232 [3-pin 3.5mm phoenix connector] |
| General Features | |
| Video Bandwith | 18Gbps |
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 |
| Color | 8/10/12bit |
| HDR | HDR, HDR10, HDR10+, Dolby Vision, HLG |
| HDCP | 2.3/2.2 and 1.4 |
| Audio Formats | HDMI IN/OUT: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X, DSD L/R OUT: PCM 2.0CH |
| Management Features | |
| Management and Control | IR Control, Hot Key Control, RS232 (3pin Phoenix) with API |
| Others | |
| Power Connection | Input: AC 100-240V 50/60Hz, Output: DC 12V/1A |
| Working Temperature | 32 – 104°F / 0 – 40°C |
| Humidity Range | 20 – 80% RH (no condensation) |
| Storage Temperature | -4 – 140°F / -20 – 60°C |
| Dimensions | 220mm × 100mm × 30mm – Width/Depth/Height, Metal Enclosure |
| Weight | 626 g |
| Power Value/Consumption | Typical value: 5.18W Standby mode: 0.6W |
| Mounting | Desktop Metal and Black / Optional Rack Mount |
| ESD Protection | Human body model — ±8kV (Air-gap discharge) & ±4kV (Contact discharge) |
| Conformity | |
| EU/USA | CE/FCC/UL |
| Package Details | |
| Package Contents | 1 x 4K60 2×1 Dual Monitor KVM Switcher 1 x IR Remote 1 x 3pin-3.81mm Phoenix Connector (male) 1 x Fixed Frequency 38KHz IR Receiver Cable (1.5 meters) 2 x USB Cable (USB 3.0, Type A to Type B, 1.8 meters) 4 x HDMI Cable (male to male, 1.5 meters) 2 x Mounting Ears 4 x Machine Screws (KM3*4) 1 x 12V/1A Multinational Locking Power Supply 1 x User Manual |
