- HDMI 1.3 and HDCP 1.4 compliant
- Supports resolutions up to 1920×1200@60Hz with 4:4:4 color sampling
- Supports video bandwidth up to 4.95Gbps
- Configurable H.265 and H.264 video compression
- Extends signals up to 100m / 328ft per network link over CAT5e/6/6A/7 cable
- Supports point-to-point signal extension
- Supports one-to-many signal distribution and multicast
- Supports distributed matrix switching over a Gigabit Ethernet network
- Supports video wall configurations up to 9×9
- Intelligent video wall management for flexible screen layouts
- Encoder provides a local HDMI loop output
- Supports main-stream and sub-stream encoding
- Supports LPCM 2.0CH audio at 32, 44.1 and 48kHz
- Analog audio embedding and de-embedding
- USB/KVM extension in one-to-one and one-to-many configurations
- Bi-directional IR and RS-232 pass-through
- RS-232 Guest Mode for external device control
- Standalone matrix switching using local IR or RS-232 without a controller
- Stream parameters configurable through Web GUI or Controller Box
- Controlled via IR, RS-232, TCP/IP, Web GUI or Controller Box
- IEEE 802.3af Class 3 PoE powered-device support
- Smart network-based architecture for flexible and scalable installation
| Input and Output | |
| Inputs & Outputs | 1 x HDMI1.3 OUT with HDCP1.4 1 x AUDIO OUT [3-pin phoenix connector] 1 x IR IN [3.5mm audio jack, 12V IR], 1 x IR OUT [3.5mm audio jack, 12V IR] – Wideband 20K – 60 KHz, 12Vp-p 2 x USB Devices [Type A, 4-pin female] |
| Inputs Resolution | Up to 1920×1080@60Hz 4:4:4 |
| Outputs Resolution | Push stream resolution: Same as input, 3840×2160, 1920×1080, 1280×720, 640×480 Push stream frame rate: 5~60Hz |
| Network | 1x LAN (POE) (RJ45 connector), Gigabit |
| General Features | |
| Video Bandwith | 4.95Gbps |
| Color Space | RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 Push stream encoding: 4:2:0 |
| Video Compression Standart | H.265/H.264 – 0.1 to 32 Mbps bitrate and 5 to 60 Fps support – VBR or CBR HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) ONVIF |
| Color | 8/10/12bit (HDMI Input), 8 bit Push Stream Output |
| Audio Formats | LPCM 2CH 48KHz |
| L/R Out Audio Parameters | Output Impedance: 330 Ohms Line Input / Output Level (Maximum): 2Vrms Frequency Response: (+0.5dB, -1dB) 20Hz to 20kHz Audio S/N Ratio: >90dB@2Vrms, 1kHzA-weighted Audio THD+N: <0.05%@2Vrms, 1KHz |
| Transmission Distance | 100m (CAT5E/6/6A/7) |
| Management Features | |
| Management and Control | TCP/IP, Web GUI, RS232 with API |
| Others | |
| Power Connection | AC100 – 240V 50/60Hz, DC 12V/1A |
| Working Temperature | 14 – 113°F / -10 – 45°C |
| Humidity Range | 20 – 90% RH (no condensation) |
| Storage Temperature | -4 – 140°F / -20 – 60°C |
| Dimensions | 204mm × 95mm × 21.5mm – Width/Depth/Height, Metal Enclosure |
| Weight | 470 gr |
| Power Value/Consumption | 3.48W (Max.) |
| Mounting | Desktop Metal – Black, Optional Rack Kit |
| ESD Protection | IEC 61000-4-2: ± 15kV (Air-gap discharge) & ± 8kV (Contact discharge) |
| Certifications | |
| EU/USA | CE/FCC/UL |
| Package Details | |
| Package Contents | 1 x 1080p@60 over IP 100M/1GbE RX 3 x 3pin-3.81mm Phoenix Connector (male) 1 x IR Blaster Cable (1.5 meters) 1 x IR Receiver Cable (1.5 meters) 1 x 12V/1A Locking Power Adapter 2 x Mounting Ear 4 x Machine Screw (KM3*4) 1 x User Manual |
