- Supports 6 Inputs
- 1 x HDMI 1.4
- 1x HDMI 2.0
- 2 x DVI
- 1 x DP1.2
- Multiple 20 x 1G RJ45 / 2 x 10G Fiber Outputs for Led Screen
- 1 x Audio output
- 13 Million Pixels load capacity
- Maximum width resolution 16384 pixels or Maximum height resolution 8192 pixels
- 6 x Layer support with smooth scaling effect
- Support USB cascading up to 64 devices
- Automation control unit
- Ethernet input and output, RS232 input and output
- HDCP 1.4 Support
- Switching, Cropping, Scaling and PIP
| Hardware | ||
| System Architecture | FPGA | |
| Control and Config | ||
| RS232 | 1 x RS232 Serial Port – RJ11 | |
| USB | 1 x USB In and 1 x USB Out – Cascade up to 64 Devices | |
| BUTTON | Front Panel Button Control and Front small LCD screen | |
| General Features | ||
| Power Supply | 100 – 240V, 50-60Hz – 50 Watt Power consumption | |
| Working Temperature | -20˚C~60˚C | |
| Working Humidity Range | 0~80% RH (no condensation) | |
| Storage Temperature | -30˚C~80˚C | |
| Dimensions | 482.6 mm × 88 mm × 414.1 mm – W/H/D, Compatible with 19″ Rack Cabin | |
| Weight | 4.83 kg | |
| Power Value | 50 W PSU | |
| Mounting | 2U Rack Cabinet | |
| Certification | ||
| EU/USA | CE and ROHS DoC | |
| Package Details | ||
| Weight (packaged) | 6.62 kg | |
| Package Content | 1 x Curve16/PVL20 , Power Cable , User Manual |
| Curve16 PVL20 | |
| Input | 1xHDMI2.0 (with audio) up to 4096×2160@60Hz, 8 Bit, 4:2:2, 4:4:4 Color sampling. 1 x HDMI1.4 (with audio) up to 1920×1200@60Hz, 8 Bit, 4:2:2, 4:4:4 Color sampling. 2 x DVI up to 1920×1200@60Hz, 8 Bit, 4:2:2, 4:4:4 Color sampling. 1xDP1.2 up to 4096×2160@60Hz, 8 Bit, 4:2:2, 4:4:4 Color sampling. 1 x audio Line Input – 3.5 mm |
| Output | 20 x 1Gbit RJ45 Ports, each ports support 650.000 pixel, 1 x audio Line Output – 3.5 mm 2x10G Fiber outputs |
| Loading Pixel | 13 Million Pixel |
| HDCP | Support 1.4 |
| EDID | Supported |
| Software | Designer VL |
